Flexicham
Countersink tools
Compliance axial
Countersinking tool FLEXICHAM for economical deburring of drill holes
Type | FLEXICHAM 200 | FLEXICHAM 260 | FLEXICHAM 580 |
Article-No. | 3040.205 | 3030.220 | 3030.221 |
Power | 830 W | 370 W | 370 W |
Idling speed | 540 rpm | 520 rpm | 1'180 rpm |
Speed adjustment range | 50 - 200 rpm | 75 - 320 rpm | 150 - 680 rpm |
Rated torque | 27 Nm | 14 Nm | 6.3 Nm |
Compliance movement (axial) | 16 mm | 12 mm | 12 mm |
Compliance force at 6 bar | approx. 135 N | approx. 60 N | approx. 60 N |
Air consumption | 17 l/s | 8.3 l/s | 8.3 l/s |
Cutter | 90° / Ø40 mm | 90° / Ø26 mm | 90° / Ø12.4 mm |
Tool insert mounting | Ø10 mm | Ø10 mm | Ø8 mm |
Weight | 7.0 kg | 3.5 kg | 3.5 kg |
