Flexitool Serie 200
Deburring tools
with and without compliance
Tool for drilling and threading FLEXITOOL SERIES 200 for economical deburring
Type | FLEXITOOL 210 | FLEXITOOL 250 | FLEXITOOL 270 |
Article-No. | 3145.210 | 3145.250 | 3145.270 |
Power | 830 W | 830 W | 830 W |
Idling speed | 2'550 min-1 | 570 min-1 | 570 min-1 |
Rated speed | 1'280 min-1 | 290 min-1 | 290 min-1 |
Compliance movement (axial) | 16 mm | ||
Compliance force at 6 bar | approx. 135 N | ||
Air consumption | 17 l/s | 17 l/s | 17 l/s |
Tool mounting | Shaft Ø16j6 x 40 mm | Shaft Ø16j6 x 40 mm | Collet ER25 Ø8 mm |
Weight | 2.3 kg | 2.5 kg | 7.0 kg |
