Flexicut 100
Milling tools
Compliance radial
milling tool FLEXICUT 100 for economical deburring
Article-No. | 1105.200 |
Power | 100 W (0.13 hp) |
Idling speed | 85'000 rpm |
Compliance radial in all directions | ± 2.5° / ± 5 mm (at collet) |
Compliance torque | 0.4 Nm (0.3 ft lbs) at 6 bar |
Compliance force | 3.5 N (0.8 lbs) at 6 bar (at collet) |
Feed forward rate | 5 - 200 mm/sec. |
Air consumption | 2.8 l/s (5.9 cfm) |
Collet | Ø 3 mm |
Max. tool diameter | Ø 6 mm |
Weight | 1.76 kg (3.9 lbs) |
