Flexicut 370
FLEXICUT 370 | Article-No. 1100.370 |
Power | 300 W (0.41 hp) at 35'000 rpm |
Idling speed | 35'000 rpm |
Max. Speed | 60'000 rpm |
Compliance radial in all directions | ± 4.2° / ± 8 mm (at collet) |
Compliance torque | 1.04 Nm (0.77 ft lbs) at 6 bar (87 psi) |
Compliance force | 8 N (1.8 lbs) at 6 bar (87 psi) (at collet) |
Feed forward rate | 5 - 250 mm/sec. |
Collet | Ø 6 mm |
Weight | 4.8 kg (10.58 lbs) |
CONTROLLER 350 | Article-No. 5163.200 |
Input Voltage | AC 100 - 240 V, 50/60 Hz, 1.8 A |
Output | AC 33 V, 0 - 1 kHz, 3 Phase, 2.4 A |
External Control Signal | Input: 9 Digital (Photo Coupler), 1 Analog Output: 1 Photo Coupler, 9 MOS Relay, 2 Relay Contact, 3 Analog |
Degree of protection | IP X0 |
Weight | 2.8 kg (6.2 lb) |
