Finishstation 2200
Type | FINISHSTATION 1200 | FINISHSTATION 2200 |
Article-No. | 1014.210 | 1014.200 |
Power | 1.2 kW | 2.2 kW |
Rated speed | 1'500 rpm | 1'500 rpm |
Max. Compliance movemen (radial) | 45 mm | 45 mm |
Compliance force | 30 N to 120 N | 30 N to 120 N |
Feed forward rate | 50 - 200 mm/s | 50 - 200 mm/s |
Rotation directions | reversible | reversible |
Degree of protection | IP 44 | IP 44 |
Insulation class | F | F |
Max. Wheel diameter | Ø 300/20 x 30 | Ø 400/35 x 30 |
Weight | ca. 80 kg | ca. 100 kg |
