Finishtool Serie 200
Grinding- and brushing tools
Compliance radial
Grinding tool FINISHTOOL 200 for economical deburring
Type | FINISHTOOL 220 | FINISHTOOL 221 | FINISHTOOL 225 | FINISHTOOL 231 | FINISHTOOL 233 |
Article-No. | 3076.210 | 3076.211 | 3076.215 | 3076.231 | 3076.233 |
Power | 840 W | 840 W | 840 W | 620 W | 620 W |
Idling speed | 2'500 rpm | 4'200 rpm | 6'700 rpm | 3'550 rpm (r) | 5'250 rpm (r) |
Rated speed | 1'280 rpm | 2'100 rpm | 3'300 rpm | 1'700 rpm (r) | 2'650 rpm (r) |
Compliance movement | 34 mm (radial) | 34 mm (radial) | 34 mm (radial) | 34 mm (radial) | 34 mm (radial) |
Compliance force * at 6 bar | approx. 140 N | approx. 140 N | approx. 140 N | approx. 140 N | approx. 140 N |
Feed forward rate | 50 - 200 mm/s | 50 - 200 mm/s | 50 - 200 mm/s | 50 - 200 mm/s | 50 - 200 mm/s |
Air consumotion | 17 l/s | 17 l/s | 17 l/s | 14.5 l/s | 14.5 l/s |
Motor shaft | Ø16 x 40 mm | Ø16 x 40 mm | Ø16 x 40 mm | Ø16 x 40 mm | Ø16 x 40 mm |
Wheel diameter | 100 - 250 mm | 100 - 250 mm | 100 - 250 mm | 100 - 250 mm | 100 - 250 mm |
Weight | 7 kg | 7 kg | 7 kg | 7 kg | 7 kg |
* without dead load
(r) rotating direction reversible
