Swingtool Serie 100
Brushing- and grinding tools
Compliance pendulous
Brush tool SWINGTOOL 100 for economical deburring
SWINGTOOL | 125 | 128 | 155 | 158 | 178 | 181 | 185 | 186 |
Article-No. | 1112.125 | 1112.128 | 1112.155 | 1112.158 | 1112.178 | 1112.181 | 1112.185 | 1112.186 |
Power | 390 W | 240 W | 390 W | 240 W | 240 W | 600 W | 1.0 kW | 1.0 kW |
Idling speed (rpm) | 5'600 | 3'840 (r) | 3'100 | 2'090 (r) | 14'000 (r) | 15'000 | 7'000 | 7'000 |
Rated speed (rpm) | 2'600 | 1'960 (r) | 1'460 | 1'090 (r) | 7'000 (r) | 8'000 | 5'600 | 5'600 |
Compliance (pendulous) | ± 3.8° | 12 mm | ± 3.8° | ± 3.8° | ± 3.8° | ± 3.8° | ± 3.8° | ± 3.8° |
Compliance torque at 6 bar | 2.4 Nm | 2.4 Nm | 2.4 Nm | 2.4 Nm | 2.4 Nm | 2.4 Nm | 2.4 Nm | 2.4 Nm |
Feed forward rate (mm/s) | 5 - 100 | 5 - 100 | 5 - 100 | 5 - 100 | 5 - 100 | 10 - 200 | 5 - 100 | 10 - 200 |
Air consumption | 8.3 l/s | 8.3 l/s | 8.3 l/s | 8.3 l/s | 7.8 l/s | 17.5 l/s | 22 l/s | 22 l/s |
Motor shaft | Ø 12x31.5 | Ø 12x31.5 | Ø 16x40 | Ø 12x31.5 | ||||
Collet | Ø6 mm | Ø6 mm | Ø6 mm | |||||
Weight | 3.5 kg | 3.5 kg | 3.5 kg | 3.5 kg | 3.5 kg | 3.8 kg | 3.8 kg | 3.8 kg |
(r) rotating direction reversible
