Swingtool Serie 200
Brushing- and grinding tools
Compliance pendulous
Brush tool SWINGTOOL 200 for economical deburring
SWINGTOOL | 220 | 222 | 225 | 230 | 232 |
Article-No. | 3126.220 | 3126.222 | 3126.225 | 3126.230 | 3126.232 |
Power | 840 W | 840 W | 840 W | 620 W | 620 W |
Idling speed | 2'500 rpm | 4'200 rpm | 6'700 rpm | 3'350 rpm (r) | 5'250 rpm (r) |
Rated speed | 1'280 rpm | 2'100 rpm | 3'300 rpm | 1'700 rpm (r) | 2'650 rpm (r) |
Compliance (pendulous) | ±3.8° | ±3.8° | ±3.8° | ±3.8° | ±3.8° |
Compliance torque at 6 bar | 10.5 Nm | 10.5 Nm | 10.5 Nm | 10.5 Nm | 10.5 Nm |
Feed forward rate | 20 - 200 mm/s | 20 - 200 mm/s | 20 - 200 mm/s | 20 - 200 mm/s | 20 - 200 mm/s |
Air consumption | 17 l/s | 17 l/s | 17 l/s | 14.5 l/s | 14.5 l/s |
Motor shaft | Ø16j6 x 40 | Ø16j6 x 40 | Ø16j6 x 40 | Ø16j6 x 40 | Ø16j6 x 40 |
Weight | 7.5 kg | 7.5 kg | 7.5 kg | 7.5 kg | 7.5 kg |
(r) rotating direction reversible
