Article-No. | 3105.251 |
Tool adapter | SK 50 |
Powered by | Air motor |
Power | 240 W |
Idling speed | 35'000 rpm |
Compliance radial in all directions | ± 4.2° / ± 8 mm (at collet) |
Compliance torque | 1.04 Nm (2.54 ft lbs) at 6 bar (87 psi) |
Compliance force | 8 N at 6 bar (87 psi) (at collet) |
Feed forward rate | 2 - 15 m/min |
Air consumption | 7.5 l/s (15.9 cfm) |
Air supply | Through the main spindle op the machining centre |
Air treatment | Service unit with filter and oiler, set for 2-3 drops/min |
Collet | Ø 6 mm (optional 3 & 8 mm & 1/4 |
Weight | 7.6 kg (16.8 lb) |
