Direktöler / Directoiler
Type | DIRECTOILER 01 | DIRECTOILER 11 | DIRECTOILER 03 | DIRECTOILER 13 |
Article-No. | 1126.201 | 1126.211 | 1126.203 | 1126.213 |
Number of lubrication points (Tools) | 1 | 1 | 3 | 3 |
Adjustable supply quantity | 3 - 30 mm3 / stroke | 3 - 30 mm3 / stroke | 3 - 30 mm3 / stroke | 3 - 30 mm3 / stroke |
Incl. actuation valves | 0 | 1 x (24 VDC) | 0 | 3 x (24 VDC) |
Actuator medium | Compressed air 3 - 7 bar | Compressed air 3 - 7 bar | Compressed air 3 - 7 bar | Compressed air 3 - 7 bar |
Lubricant | Oil on mineral or synthetic basis | Oil on mineral or synthetic basis | Oil on mineral or synthetic basis | Oil on mineral or synthetic basis |
Operational viscosity | 10 - 1100 mm2/s | 10 - 1100 mm2/s | 10 - 1100 mm2/s | 10 - 1100 mm2/s |
Container volume | 1 Litre | 1 Litre | 1 Litre | 1 Litre |
Mixing valve 1/4 | incl. 1 pc | incl. 1 pc | incl. 3 pcs | incl. 3 pcs |
Length of polyamide tube | 1 x 5 m | 1 x 5 m | 3 x 5 m | 3 x 5 m |
Level monitoring | electrical | electrical | electrical | electrical |
Weight | 1 kg | 1 kg | 1.5 kg | 1.5 kg |
