Flextapper Serie 100
Deburring tools
with and without compliance
Tool for threads FLEXTAPPER SERIES 100 for economical machining
Type | FLEXTAPPER 110 | FLEXTAPPER 120 |
Article-No. | 3208.200 | 3146.220 |
Power | 230 W | 230 W |
Idling speed | 840 rpm | 385 rpm |
Rated speed | 435 rpm | 190 rpm |
Compliance movement (axial) | 12 mm | 12 mm |
Compliance force at 6 bar | approx. 60 N | approx. 60 N |
Thread size in Aluminium | ≤M8 (Reference value) | ≤M10 (Reference value) |
Thread size in Steel | ≤M6 (Reference value) | ≤M8 (Reference value) |
Air consumption | 7.8 l/s | 7.8 l/s |
Tool mounting | für M5 | Collet ESX12 Ø2-7 mm |
Weight | 4.2 kg | 4.4 kg |
