Angle-Cutter Serie 400
Type | ANGLE-CUTTER 410 | ANGLE-CUTTER 415 | ANGLE-CUTTER 420 | ANGLE-CUTTER 425 |
Article-No. | 3074.210 | 3074.215 | 3074.220 | 3074.225 |
Powered | 4.5 kW | 4.5 kW | 4.5 kW | 4.5 kW |
Idling speed | 8'500 rpm | 8'500 rpm | 6'600 rpm | 6'600 rpm |
Cutting force monitoring (*) | Sensor | Sensor | ||
Max. Cutting force at 6 bar (*) | 188 N | 188 N | ||
Air consumption | 60 l/s | 60 l/s | 60 l/s | 60 l/s |
Wheel centring | Ø 7/8 | Ø 7/8 | Ø 7/8 | Ø 7/8 |
Wheel diameter | up to 180 mm | up to 180 mm | up to 230 mm | up to 230 mm |
Weight | 8 kg | 9.8 kg | 8 kg | 9.8 kg |
(*) The version with the cutting force monitoring permits the angle-motor to move backwards if it is overloaded caused by an excessive feed rate. This movement is monitored by a sensor and can consequently stop the robot movement immediately via interrupt. This feature prevents a damage of the cutting wheel. The cutting force is adjustable by a control valve.
