Article-No. | 3164.310 |
Power | 1.3 kW (1.74 hp) |
Idling speed | 25'000 rpm |
Rated speed | 20'000 rpm |
Compliance radial in all directions | ± 3.2° / ± 16 mm (at collet) |
Compliance torque | 0 ... 15 Nm at Connection 1; 5 ... 30 Nm at Connection 1 and 2 |
Compliance force | 109 N (24.5 lbs) at 6 bar (87 psi) (at collet) |
Feed forward rate | 10 - 300 mm/sec. |
Air consumption | 22 l/s (46.6 cfm) |
Collet | Ø 8 mm, 5/16 |
Weight | 7.45 kg (16.1 lb) |
