Milling tools
Compliance radial

milling tool FLEXICUT 2600 for economical deburring

Article-No.	3160.200
Power	2.6 kW (3.5 hp)
Maximal toque	0.83 Nm (0.6 ft lbs)
Maximal speed	30'000 rpm
Compliance radial in all directions	± 3.2° / ± 16 mm (at collet)
Compliance torque	0 ... 15 Nm at Connection 1; 5 ... 30 Nm at Connection 1 and 2
Compliance force	109 N (24.5 lbs) at 6 bar (87 psi) (at collet)
Feed forward rate	10 - 300 mm/sec.
Collet	ER 16 Ø 10-9 mm, 3/8
Weight	12 kg (26.5 lb)
