Swingcut 100
Milling tools
Compliance pendulous
milling tool SWINGCUT 100 for economical deburring
Article-No. | 1121.200 |
Power | 100 W (0.13 hp) |
Idling speed | 85'000 rpm |
Compliance radial in two directions | ± 3.8° / ± 6 mm (at collet) |
Compliance toque | 0.9 Nm (0.66 ft lbs) bei 6 bar (87 psi) |
Compliance force | 10 N (2.2 lbs) at 6 bar (87 psi) (at collet) |
Feed forward rate | 5 - 200 mm/sec. |
Air consumptions | 2.8 l/s (5.9 cfm) |
Collet | Ø 3 mm |
Weight | 2.3 kg (5.1 lb) |
