Filing tools
Compliance pendulous

Filing tool SWINGFILE 4000 for economical deburring

Article-No.	1008.200
Strokes per min	4'000
Stroke length	1 - 5 mm adjustable
Compliance pendulous in two directions	± 3.8° / ± 8.5 mm (at collet)
Compliance torque	2.4 Nm at 6 bar
Compliance force	17 N at 6 bar (at collet)
Feed forward rate	5 - 150 mm/s
Air consumption	4.4 l/s
Collet	Ø3 mm
Weight	2.2 kg
