Circ-Flexibrush Serie 200
Brushing tools
Compliance axial
Brush tool CIRC-FLEXIBRUSH SERIES 200 for economical deburring
CIRC-FLEXIBRUSH | 219 | 222 | 225 | 220 | 230 | 232 |
Article-No. without compensation springs (w) | 3098.219 | 3098.222 | 3098.225 | 3098.220 | 3098.230 | 3098.232 |
Article-No. with compensation springs (w) | 3098.319 | 3098.322 | 3098.325 | 3098.320 | 3098.330 | 3098.332 |
Power | 840 W | 840 W | 840 W | 620 W | 620 W | 620 W |
Idling speed | 2'500 rpm | 4'200 rpm | 6'700 rpm | 2'000 rpm (r) | 3'350 rpm (r) | 5'250 rpm (r) |
Rated speed | 1'280 rpm | 2'100 rpm | 3'300 rpm | 1'020 rpm (r) | 1'700 rpm (r) | 2'650 rpm (r) |
Compliance movement | 16mm (axial) | 16mm (axial) | 16mm (axial) | 16mm (axial) | 16mm (axial) | 16mm (axial) |
Compliance force at 6 bar | approx. 135 N | approx. 135 N | approx. 135 N | approx. 135 N | approx. 135 N | approx. 135 N |
Feed forward rate (mm/s) | 20 - 200 | 20 - 200 | 20 - 200 | 20 - 200 | 20 - 200 | 20 - 200 |
Air consumption | 17 l/s | 17 l/s | 17 l/s | 17 l/s | 14.5 l/s | 14.5 l/s |
Motor shaft | Ø16j6x40 | Ø16j6x40 | Ø16j6x40 | Ø16j6x40 | Ø16j6x40 | Ø16j6x40 |
Weight | 6.7 kg | 6.7 kg | 6.7 kg | 6.7 kg | 6.7 kg | 6.7 kg |
(r) rotating direction reversible
(w) with dead weight compensation springs
