Flexibelt 2200
Belt-grinding machines
Compliance radial
Belt grinding station FLEXIBELT 2200 for economical deflashing and deburring
Type | FLEXIBELT 2200 | FLEXIBELT 2200 |
Article-No. | 1051.200 | 1051.201 |
Power | 2.2 kW | 2.2 kW |
Rated speed | 1'420 rpm | 1'420 rpm |
Rated belt speed | 22.3 m/s | 22.3 m/s |
Max. Compliance movement | 40 mm | 40 mm |
Compliance force | 17 N to 120 N | 17 N to 120 N |
Power supply | 4 x 400 V / 50 Hz | 4 x 400 V / 50 Hz |
Degree of protection | IP 44 | IP 44 |
Insulation class | F | F |
Belt length | 4 m | 4 m |
Max. Belt width | 100 mm (optional 125 mm) | 100 mm (optional 125 mm) |
Max. Belt tension force | 483 N (at 6 bar) | 483 N (at 6 bar) |
Rotation device | keine | 2 x 90° |
Weight | approx. 250 kg | approx. 300 kg |
