Flexibrush Serie 100
Brushing tools
Compliance axial
Brush tool FLEXIBRUSH SERIES 100 for economical deburring
FLEXIBRUSH | 125 | 128 | 155 | 158 | 170 | 181 | 185 | 186 |
Article-No. without compensation springs (w) | 3030.215 | 3030.218 | 3030.216 | 3030.219 | 3030.240 | 3030.251 | 3030.255 | 3030.256 |
Article-No. with compensation springs (w) | 3030.315 | 3030.318 | 3030.316 | 3030.319 | 3030.340 | 3030.351 | 3030.355 | 3030.356 |
Power | 390 W | 240 W | 390 W | 240 W | 760 W | 600 W | 760 W | 760 W |
Idling speed (rpm) | 5'600 | 3'840 (r) | 3'100 | 2'090 (r) | 7'000 | 15'000 | 7'000 | 7'000 |
Rated speed (rpm) | 2'600 | 1'960 (r) | 1'460 | 1'090 (r) | 5'600 | 8'000 | 5'600 | 5'600 |
Compliance movement | 12 mm (axial) | 12 mm (axial) | 12 mm (axial) | 12 mm (axial) | 12 mm (axial) | 12 mm (axial) | 12 mm (axial) | 12 mm (axial) |
Compliance force at 6 bar | approx. 60 N | approx. 60 N | approx. 60 N | approx. 60 N | approx. 60 N | approx. 60 N | approx. 60 N | approx. 60 N |
Feed forward rate (mm/s) | 5 - 100 | 5 - 100 | 5 - 100 | 5 - 100 | 10 - 200 | 10 - 200 | 10 - 200 | 10 - 200 |
Air consumption | 8.3 l/s | 8.3 l/s | 8.3 l/s | 8.3 l/s | 18.9 l/s | 17.5 l/s | 18.9 l/s | 18.9 l/s |
Motor shaft | Ø 12x31.5 | Ø 12x31.5 | Ø 16x40 | Ø 12x31.5 | ||||
Collet | Ø 6 mm | Ø 6 mm | Ø 6 mm | Ø 6 mm | ||||
Weight | 3.5 kg | 3.7 kg | 3.5 kg | 3.7 kg | 4.9 kg | 3.8 kg | 4.2 kg | 4.1 kg |
(r) rotating direction reversible
(w) with dead weight compensation springs
